L-Acoustics K1 User Manual

Corrective maintenance
D/R - LF speaker
Tools
• torque screwdriver
• 5 mm hex bit
Repair kit
KR HPPH154
Kit HP PH154 Speaker 15'' - 8 ohms
×1 ×8
300_2 S100054
15" speaker - 8 ohms M6×30 hex
Prerequisite
Grill disassembled. See Grill (p.36).
Exploded view
For safety reasons, always use the new screws and spare parts provided in the KR.
If no new screws are available, use blue threadlocker.
x8
5 N.m
5 mm
K1 user manual (EN) version 6.0 37

L-Acoustics K1 Specifications

General

Frequency Response	35 Hz - 20 kHz
Nominal Impedance	8 ohms
Enclosure Material	Baltic birch plywood
Components	2 x 15" LF, 4 x 6.5" MF, 3 x 3" HF
Amplification	External
Connectors	2 x NL4
