Heat Exchanger Parts (80 MBH to 140 MBH)
No Description Part Number
2
O-Ring P7 FT1601
3
O-Ring P22 FT1514
4
0.3” Packing FT1060
5
3/4” Packing FT1646
6
1” Packing FT1691
N-1
M4 Nut FT1061
B-1
M3*6 PH FT1062
B-3
M4*8 PH FT1063
B-5
M4*8 TH FT1520
B-7
M4*10 TH FT1719
B-8
M4*10 TH FT1064
B-12
M4*14 PH FT1065
B-13
M4*14 PW FT1066
31
Exhaust Pipe FT1067
32
Exhaust sensor BK FT1529
33
Exhaust overheat sensor FT1307
34
Piping connector (down) FT1666
35
Heat Exchanger Ass'y (80,100K) FT1852
Heat Exchanger Ass'y (120,140K) FT1068
35-1
Burner Ass’y FT1309
35-2
Overheat sensor FT1310
35-3
Burner upper case FT1658
35-4
Ceramic Paper(TBD) FT1659
35-5
Burner FT1314
35-6
Burner case sealing O-ring FT1661
35-7
Ingiter FT1315
35-8
Ignitor Gasket FT1316
35-10
Refractory FT1665
38
Flame detector sensor Cover FT1069
39
Flame detector sensor FT1327
40
Flame detector sensor BK FT1669
41
Outlet Pipe (80,100K) FT1853
Outlet Pipe (100,140K) FT1070
42
CH return Pipe-1 FT1071
43
Pump FT1672
44
CH return sensor FT1635
45
CH return Pipe-2 FT1072
46
Condensate Trap Ass’y FT1073
47
Condensate Drain Hose FT1329
48
Clamp Φ23 FT1682
49
Condensate trap connector FT1330
