D SERIES Lake Quick Start Guide rev 3.0.4
14. Faults and Warnings
14. Faults and Warnings
Category/Type Name On screen text Description Action
FRAME
Warning
Lake Controller ofn ine CTRL OFFLINE
Frame unable to m nd Lake controller
on the network
Check network cabling/
network if controller
expected on the network
Warning
AES / Dante clock slipping CLOCK SLIPPING
Frame not able to lock to incoming
AES stream or Dante clock slipping.
Check AES sender and
clock conm guration or
Dante clock settings
Warning
Dante device name conn ict NAME CONFLICT
Two or more devices on the network
with the same Dante name
Review Dante
conm guration
Warning
Dante module not detected
DANTE NEEDS
SERVICE
Lake cannot detect a functioning
Dante module
Restart device; if not
cleared it needs service
to operate Dante
Warning
Dante module with
incompatible m rmware
DANTE FW INVALID
Dante module not loaded
with correct FW
Retry updating the m rmware
with LakeUpdate
Warning
Dante module disabled DANTE DISABLED
Dante module not communicated
correctly or other internal
conm guration fault
Restart device; if not
cleared it needs service
Warning
Sense fault DSP SENS FLT:DSP
Voltage and current sensing on amplim er
output faulty. Audio continues but
protection might be compromised.
No load monitoring
Restart device; if not
cleared it needs service
Warning
A/D converter power
supply fault
A/D PSU FAULT
Voltage supply to the analog input
converters faulty
Restart device; if not
cleared it needs service for
analog input to work
Fault
Audio Fault AUDIO FAULT
Internal audio interface
not functioning
Restart device; if not
cleared it needs service
Fault
DICO communication fault DICO COMM FAULT
Communication fault between host
and amplim er platform
Restart device; if not
cleared it needs service
TEMP
Warning
Temperature warning
power supply
TEMP WARN:PSU
Power supply temperature
approaching critical levels
Improve cooling or reduce
o
u
tput power to avoid
temperature becoming
critical
Warning
Temperature warning
DSP area
TEMP WARN:DSP
DSP area temperature approaching
critical levels
Improve cooling or reduce
output power to avoid
temperature becoming
critical
Warning
Power supply
Temperature Limit
PTL ACTIVE
Amplim er is reducing output power
to avoid power supply temp
fault protection
Improve cooling or reduce
output power to avoid
limiting
Warning
Amp channel
Temperature Limit
ATL ACTIVE
Amplim er channel is reducing output
power to avoid amplim er channel
temp fault protection
Improve cooling or reduce
output power to avoid
limiting
