15) LIST OF PARAMETERS TO SELECT FOR THE CONTROL UNITS
DIP-SWITCH S1
SLAVE
MASTER
DIP 1 = PUSH & GO
DIP 2 = WIND STOP
DIP 3 = CYCLIC FUNCTION (repeated opening and closing)
DIP 4 = ELECTRO-LOCK OPERATING MODE
DIP 5 = CLOSING BY SPRING AND MOTOR
DIP 6 = INITIAL SET-UP
DIP 7 = DOOR OPEN/NIGHT LOCK (with function selector switch on II)
DIP 8 = COURTESY MODE FOR THE DISABLEDI
DIP 9 = 10 sec OPENING WITH “NIGHT LOCK” WORK PROGRAM
DIP 10 = AUTOMATIC INCREASE OF THE HOLD TIME
DIP 11 = SELECTION OF THE FUNCTION SELECTOR DEVICE
DIP 12 = ADJUSTMENT OF FUNCTIONS & POTENTIOMETERS VIA SELECTOR
DIP-SWITCH S2
DIP 1 = STEPPING MODE
DIP 2 = ELECTRO-LOCK RELEASE IN FREE DOOR MODE
DIP 3 = PEDESTRIAN OPENING WITH FREE DOOR (OFF)/NIGHT LOCK (ON)
DIP 4 = PEDESTRIAN OPENING FUNCTION
DIP 5 = WING DELAY ON STARTING
DIP 6 = MASTER/SLAVE CONTROL UNIT SET-UP
DIP 7 = “DOUBLE-WING DOOR ” OPERATING MODE
DIP 8 = PHOTOCELL OPERATING MODE
DIP 9 = PHOTOCELL OPERATING MODE
DIP 10 = OPERATION OF THE RADAR INPUTS
DIP 11 = RESETTING OF TECHNICAL MENU DEFAULT VALUES (see TECHNICAL MENU)
DIP 12 = CONTROL UNIT RESET
33
14) PEDESTRIAN OPENING
The pedestrian opening function can only be used for a swing door with two wings. It is therefore essential for the actuators
to be set up for operation as a DOUBLE-WING DOOR (see sect.13).
To enable the PEDESTRIAN OPENING function, set dipswitch 4 of S2 ON and select the condition which activates the
function by means of dipswitch 3 of S2.
A) DIP 3 S2 DIP 4 S2
OFF ON
Choose on the program selector to enable the PEDESTRIAN OPENING function.
- The status loses its original free door function in this condition.
B) DIP 3 S2 DIP 4 S2
ON ON
Choose on the program selector to enable the pedestrian opening FUNCTION.
- The status loses its original mìnight lock function in this condition.
In both case A) and B), activation of an internal or esternal RADARinput partially opens the door, i.e. the sole wing
controlled by the MASTER actuator (pedestrian wing), while the START or EMERGENCY inputs open both MASTER and
SLAVE wings.
manual pushing with the push & go function only opens the pedestrian wing.
