34
TECHNICAL MENU
3) NOT USED
4) NOT USED
5) END OF TRAVEL DISTANCE ON OPENING
6) PUSHING POWER AT END OF OPENING MANOEUVRE
7) PUSHING POWER AT END OF CLOSING MANOEUVRE ("NEPTIS/LE” version only)
8) NOT USED
9) PUSHING TIME AT END OF CLOSING MANOEUVRE ("NEPTIS/LE” version only)
10) SLOWING DISTANCE ON OPENING
11) SLOWING DISTANCE ON CLOSING
12) WINF STOP FORCE INTENSITY ON OPENING
13) WING DELAY ON START-UP IN OPENING PHASE
14) WING DELAY ON START-UP IN CLOSING PHASE
SLAVE
MASTER
PARAMETERS
POTENTIOMETERS
TM1 = O0PENING SPEED
TM2 = CLOSING SPEED
TM3 = OPENING SAFETY SENSOR CUT-OUT DISTANCE
TM4 = PUSHING POWER LIMITATION
TM5 = HOLD TIME
TM6 = UPKEEP VOLTAGE ON CLOSING
TM7 = WIND STOP FORCE INTENSITY
TM8 = PUSH & GO ACTIVATION DISTANCE
TM9 = INTENSITY OF FINAL CLOSING PUSH TO LINK ELECTRO-LOCK
TM10 = POWER OF CLOSING STROKE FOR RELEASING ELECTRO-LOCK
16) MEANINGS OF THE BUZZER SIGNALS (BEEPS)
5 BEEPS = control unit without initial set-up (press START with function selector switch in 0 position)
Long BEEP = control unit without initial set-up (keeping START depressed with function selector switch on I or II)
6 BEEPS = ENCODER not operating or disconnected
1 BEEP = programming procedure accessed via digital selector
1 BEEP = programming procedure quitted via digital selector without memorizing the data
2 BEEPS = programming procedure quitted via digital selector with data memorized
1 long BEEP (5”)= initial set-up terminated.
17) TECHNICAL SPECIFICATIONS
POWER SUPPLY 230Vac +/- 10%
Max. POWER EXT. ACCESSORIES 20W
TIPE OF OPERATION Intensive use
OPERATING TEMPERATURE -20°C / +50°C
PROTECTION DEGREE IP22
SLAVE
MASTER
1) PUSHING FORCE AT THE BEGINNING OF THE CLOSING MANOEUVRE (on closing)
2) DISTANCE AT THE BEGINNING OF THE CLOSING MANOEUVRE (on closing)
