LaboGene Fortuna 900 - Fuse Replacement Guide

Instruction manual for Fortuna
12062017QA01
Item No. 700745
CopyRight © 2017
Page 28 of 49
Product name
Catalogue No.
Light tube Fortuna 900
9.000.040.011
Light tube Fortuna 1200
9.000.040.012
Light tube Fortuna 1500
9.000.040.013
Light tube Fortuna 1800
9.000.040.014
8.3 Optional UV lights
The UV light is located on the top front wall of the working chamber. Release lamps from the fixtures
by rotating it 90º. Install the new UV-lamp performing the inverse operation.

Note
Use gloves when manipulating a germicidal UV lamp, to prevent leaving hand prints
that reduce the effects of the ultraviolet radiation.
Replace UV lamp every 2000 or 3000 hours of life.
Product name
Catalogue No.
UV light tube, all models
9.000.040.001
8.4 Replacement of fuses
All fuses are located on PCB’s accessed through the top plate located on the front top of the cabinet.
Make sure that power is cut before removing the protective top plate.
Main board
