6 Operating the Fortuna cabinets
All functions are controlled via the control panel shown below and by an electronic microprocessor
bases control system.
The control panel contains 6 buttons with LED for operating the basic functions in the cabinet, a text
display, that will show current running conditions and error messages and 5 buttons for navigational
purposes.
Button 1 with green LED light to select the fan ON/OFF at normal velocity. The green light
indicates that the fan is running at normal velocity, and that conditions are safe.
Button 2 with blue LED to select the fan ON/OFF at reduced velocity. Can be adjusted to
any level desired for individual requirements (See Service menu).
Button 3 with red light to silence the acoustic alarm.
Button 4 with blue light for normal light ON/OFF.
Button 5 with yellow light is if UV light is required for decontamination or activation of the
table top. The time for the light is set in the user menu (See User menu).
Button 6 can be connected to an internal plug in the chamber for remote on/off of the
plug/gas resettable valve.
Button 7: Window open (upwards movement).
Button 8: Only for programming/navigation.
Button 9: Only for programming/navigation.
Button 0: Window close (downwards movement).
Blue button: ENTER.
The user can by pressing enter see following User menu´s
Light intensity – in this menu the user can choose between 0-100 % light intensity to get
best light conditions. Please choose desired level and press enter.
