34 CHAPTER 3
Operating the Expert(t) 2000
TM
position, you must remove the
pedal cover.
7. Start the engine.
8. Turn on the
PUMP switch.
Hopper Door Interlock
The hopper door interlock prevents the
action of the automated arm while the
hopper top door is not fully open and
locked. Therefore, there will not be any
collision between the arm and the door
that could eventually lead to damage.
The interlock is controlled by a position
sensor or limit switch located right next
to the door lock.
Figure 18. Hopper top door position
switch
Note:The hopper bottom door can
be left either open or closed
while operating the automated
arm.
Crusher Panel
Interlock
On units equipped with this feature, the
crusher panel interlock prevents the
action of the automated arm while the
crusher panel is not fully retracted.
Therefore, there will not be any
collision between the arm and the
crusher panel that could eventually
lead to damage. The interlock is
controlled by a position or limit switch
located right next to the crusher panel.
Figure 19. Crusher panel position
switch
