45Expert(t) 2000
TM
Operator Manual
Figure 33. Packer module access
panel
5. At the packer module, locate the
settings switch found on the
harness feeding the module.
Next to the harness connector of
the packer module, a green LED
flashes on and off.
Figure 34. Packer multi-cycle
module
6. Press and hold the button on the
Settings switch for around three
to four seconds. A continuous
red light on the LED appears.
7. Press the button again the
number of times you want the
packer to cycle at a time.
Note:The module has been set at
the factory to three cycles.
Once you have entered the desired
number of cycles, the LED flashes
red/green the same number of
times to confirm you the new
settings have been stored.
8. On the controls station or the
console, press the green button
to test the new settings of the
packer multi-cycle module.
9. If the packer performs the
desired number of cycles,
re-install the access panel. The
vehicle is ready to use the new
settings.
Floor Riser
The Expert(t) 2000
TM
is equipped with a
stand-on platform on the right-hand
side of the cab to help your
standing-position driving. It allows you
to stand higher in the cab for a better
visual field, more comfortable driving,
and provides you with a safe, non
slippery surface. Also, its grid form
allows the drainage of any type of mud
or snow that can be stuck under your
boots.
Access panel
Twirl the bolts off
Settings switch
Green LED
