52 | HPI Combi Flow User Guide | Version 3.11 www.lafert.com

9.8. Parameter Group 9 – User Inputs and Output Programming

Par. Function Setting Range Default Notes

P9-01 Enable Input Source These parameters allow the user to directly select the source of the various command points.

Parameters are only adjustable if P1-13 = 0. This allows complete ﬂexibility over the drive control

functions, and interaction with the internal Function Block programming environment.

P9-02 Fast Stop Input Source

P9-03 Run Forward Input Source

P9-04 Run Reverse Input Source

P9-05 Latch Function Enable 0 OFF 0

1 ON

P9-06 Reverse Input Source See above

P9-07 Reset Input Source

P9-08 External Trip Input Source

P9-09 Terminal Control Select Source

P9-10 Speed Reference Source 1 In combination with P9-18 – P9-20, allow selection of several speed reference sources for common

applications.

P9-11 Speed Reference Source 2

P9-12 Speed Reference Source 3

P9-13 Speed Reference Source 4

P9-14 Speed Reference Source 5

P9-15 Speed Reference Source 6

P9-16 Speed Reference Source 7

P9-17 Speed Reference Source 8

P9-18 Speed Reference Select Input 0 See above

P9-19 Speed Reference Select Input 1

P9-20 Speed Reference Select Input 2

P9-21 Preset Speed Select Input 0

P9-22 Preset Speed Select Input 1

P9-23 Preset Speed Select Input 2

P9-28 Motorised Pot Up Input Source

P9-29 Motorised Pot Down Inpt Source

P9-32 Fire Mode Input Select

P9-33 Analog Output 1 Source 0 Deﬁned by P2-11 0 These parameters allow the user to overdide

the normal parameter control source for the

associated function, allowing interaction

with the internal Function Block programming

environment.
