66 | HPI Combi Flow User Guide | Version 3.11 www.lafert.com
11.5.2. IP55 380-480V 3 Phase Input, 3 Phase Output
Frame
Size
Power Rating Input
Current
Fuse or MCB
(Type B)
Maximum Cable Size Rated Output
Current
Maximum Motor
Cable Length
kW HP A Non UL UL mm AWG/kcmil A m ft
5 30 40 52.3 63 70 35 2 61 100 330
5 37 50 62.5 80 80 15 0 300MCM 72 10 0 330
5 45 60 79.5 10 0 100 15 0 300MCM 90 100 330
11.5.3. IP55 500-600V 3 Phase Input, 3 Phase Output
Frame
Size
Power Rating Input
Current
Fuse or MCB
(Type B)
Maximum Cable Size Rated Output
Current
Maximum Motor
Cable Length
kW HP A Non UL UL mm AWG/kcmil A m ft
5 37 50 59.5 80 80 35 2 54 10 0 330
5 45 60 70.4 100 90 35 2 65 100 330
11.5.4. IP66 200-240V 3 Phase Input, 3 Phase Output
Frame
Size
Power Rating Input
Current
Fuse or MCB
(Type B)
Maximum Cable Size Rated Output
Current
Maximum Motor
Cable Length
kW HP A Non UL UL mm AWG/kcmil A m ft
2 0. 75 1 3.3 6 6 8 8 4.3 100 330
2 1.5 1.5 5.3 10 10 8 8 7 10 0 330
2 2.2 3 8 10 10 8 8 10.5 10 0 330
3 4 5 14.2 25 17. 5 8 8 18 10 0 330
3 5.5 7. 5 19 . 3 25 25 8 8 24 100 330
3 7. 5 10 24.6 32 30 8 8 30 100 330
4 11 15 45.2 63 60 16 5 46 100 330
11.5.5. IP66 380-480V 3 Phase Input, 3 Phase Output
Frame
Size
Power Rating Input
Current
Fuse or MCB
(Type B)
Maximum Cable Size Rated Output
Current
Maximum Motor
Cable Length
kW HP A Non UL UL mm AWG/kcmil A m ft
2 0. 75 1 1.8 6 6 8 8 2.2 10 0 330
2 1.5 2 3.3 6 6 8 8 4 .1 100 330
2 2.2 3 4.7 6 6 8 8 5.8 10 0 330
2 4 5 7. 7 10 10 8 8 9.5 100 330
2 5.5 7. 5 11 . 4 16 15 8 8 14 10 0 330
3 7. 5 10 15 25 20 8 8 18 10 0 330
3 11 15 20.5 25 25 8 8 24 100 330
3 15 20 25.3 32 35 8 8 30 100 330
4 18.5 25 35.2 50 45 16 5 39 100 330
4 22 30 42.2 63 60 16 5 46 100 330
11
Technical Data
