OVEN - HOTPLATES - WASHING MACHINE
52
UTILITY ABOARD
LAGOON 42
WASHING MACHINE
GAS VALVES
WATER SUPPLY VALVE (US
VERSION) + OUTLET VALVE OF
THE WASHING MACHINE
1
Nota: the same layout can be observed
in the other version.
1 - Washing machine (option for
3-cabin version).
2 - 110 V - 220 V selection panel.
3 - Circuit breakers panel.
4 - Outlet valve + supply valve
of the washing machine.
5 - Hotplates.
6 - Gas valves.
7 - Oven.
4
6
2
3
7
5
