Lagoon 42 - Watermaker

68
WATER SYSTEMS
LAGOON 42
Nota: the same layout can be observed
in the other version.
1 - Control.
2 - Automatic breaker.
3 - Filters + rinsing valve.
4 - Drain valve.
5 - Sea water supply valve.
6 - Membranes.
7 - Watermaker.
7
1
2
WATERMAkER
7
6
2
3
1
6
3
5
4
5
3
1 - Watermaker + pump.
2 - Filters + rinsing valve.
3 - Sea water supply valve.
4 - Drain valve.
5 - Control.
6 - Automatic breaker.
