BILGE PUMP SYSTEM - GREY WATERS
60
WATER SYSTEMS
LAGOON 42
Nota: the same layout can be observed
in the other version.
1 - Shower pump switches.
2 - Shower drain pumps.
3 - Front / aft compartment outlet valve.
4 - Hull sump.
5 - Electric bilge pumps.
6 - Manual bilge pumps.
3
5
4
3
6
2
Each hull has the same components.
Nota: each valve in the boat is identified.
6
1 2 3 3 5
SEA-COCk
OPEN
SEA-COCk
CLOSED
1
