HEATING
56
UTILITY ABOARD
LAGOON 42
THERMOSTAT + VENTILATION SWITCH
+ HEAT CONTROL / TIMER
Nota: the same layout can be observed
in the other version.
1 - Fuel tanks.
2 - Water system valves.
3 - Boiler.
4 - Boiler exhaust outlet.
5 - Control + ventilation switch.
4
3
2
1
HEATING SYSTEM VALVES
BOILER + VALVES
5
