ELECTRICITY
73
7
ELECTRICITY
Check battery charge levels on the screen in the chart table.
SUPPLY OF THE CHARGERS
Select the power supply source (generator or supply shore socket)
using the right hand selector on the 110 V - 220 V selector board (in
the starboard hull companionway).
The 12 V consuming appliances circuit breakers are located in a cup-
board under the chart table.
They can be wound by pressing a black lug.
n 7.2 Inverter
The boat is optionally equipped with a 12 V / 110 V - 220 V / 2000 Va
inverter located in the starboard passageway cupboard.
The inverter supplies the galley sockets with 110 V - 220 V.
The power switch of the inverter and its voltmeter are located in the
starboard hull companionway.
Check that the switch on the inverter is in REMOTE position in order for
the main switch to be turned on.
n 7.1 12 V Circuit
The main domestic circuit is supplied in 12 V.
The auxiliary batteries (on-board) and the starboard engine battery are
located in the starboard engine compartment.
The port engine battery is located in the port engine compartment.
The generator battery (optional) is located in the starboard locker of
the forward swim deck.
The starboard engine and auxiliary cut-outs (on-board) are located in
the starboard engine compartment.
For safety reasons, a coupling system for the engine batteries allows
the engine to start if the relevant battery is faulty.
The port engine and coupling cut-outs are located in the port engine
compartment.
The generator includes its own cut outs located in the starboard locker
of the forward swim deck.
The batteries can be charged either by the engine alternator or by the
110 V - 220 V / 12 V - 40 A battery charger.
According to the lay out, the boat may optionally be fitted with an extra
110 V - 220 V / 12 V - 40 A charger.
The battery chargers are located in the starboard engine compart-
ment.
LAGOON 42
RECOMMENDATION
Check the battery charge during the use of the
inverter.
