RS232 PORT
The 2020 Turbidimeter may be interfaced with any IBM compatible computer
using an Interface cable (Code 1772). The meter may also be interfaced with an
RS-232 serial printer, using an appropriate cable and setting the printer
configuration to the output below.
Output: RS232 compatible, asynchronous serial, 9600 baud, no parity, 8 data bits,
1 stop bit.
Computer Connection: RS232-(1772) interface connection, 8 pin mDIN/9 pin F
D-submin.
Pin out:
5 RS-232 TxD
3 RS-232 RxD
4, 6, 8 digital ground
23
