OPERATING MANUAL PUK 5.1
EN
10. Technical data
10.1 Technical data for the welding device
The device must be used in dry rooms only.
Mains voltage ~230/115 V / 50 - 60 Hz +/-10 %
Mains fusing T 3.15/6.3 A
Power consumption 400 VA
Working voltage 30 – 43 V
No-load voltage 43 V
Switch on duration 80 %
Max. charging time 0.8 s
Shielding gas min. ARGON 4.6 (99.996 %)
Maximum gas pressure 4 bar
Protection class I
Insulation class B
Protection type IP 21S
Weight 7.92 kg
10.2 Technical data for the microscope
Optical visual protection and illumination unit for use exclusively with PUK fine welding devices. Only use
indry rooms.
Operating temperature +5 °C to +40 °C
Lamp "LED unit" 3 W / 800 mA
Protection class III
Insulation class B
Protection type IP 20
Weight 3.58 kg
10.3 Optical data for the microscope
Lens 1.0
Ocular 10 x
Working distance 140 mm
Magnification factor 10 x
Field of view 20 mm
10.4 Technical data for the LCD shutter M11 (BL)
Light shade DIN 3
Dark shade DIN 11
Switching time < 0.5 ms
26
