SPECIFICATIONS
DIMENSIONS
Cabinet 23 inches x 23 inches (58.42 cm x 58.42 cm)
Rim 25 inches x 25 inches (63.50 cm x 63.50 cm)
Height (without legs) 19-1/2 inches (49.53 cm) above counter (to top
of valves)
23 inches (58.42 cm) below counter
WEIGHT
Shipping 296 pounds (134.26 kg)
Empty 253 pounds (114.75 kg)
Operating 365 pounds (165.5 kg)
ICE BIN CAPACITY 100 pounds (45.46 kg)
1. INSTALLATION OF LANCER ICE COOLED DISPENSER
1.1 RECEIVING
Each unit is tested under operating conditions and inspected before shipment. At the time of
shipment, the carrier accepts responsibility for the unit. Upon receiving the unit, carefully inspect the
carton for visible damage. If damage exists, have the carrier note the damage on the freight bill and
file a claim with carrier. Responsibility for damage to the unit lies with the carrier.
1.2 UNPACKING
A. The ice cooled dispenser is shipped in a corrugated shipping carton. Remove the corrugated
shipping carton from the unit.
B. Remove the parts from the ice compartment.
C. Inspect the unit and parts for concealed damage. If damage exists, notify delivering carrier and
file a claim.
1.3 SELECTING A COUNTER LOCATION
A. Select a counter location close to a properly grounded electrical outlet and a water supply that
meets the requirements specified in Section 1.4 below.
B. The counter location must be able to safely support a minimum of 365 pounds (165.5 kg) after
the counter cutout is made.
1.4 WATER SUPPLY
A. Provide an adequate potable water supply The water supply line must be at least a 1/2 inches
(12.7 mm) pipe. Water pressure exceeding 50 PSI is regulated by a pressure regulator on the
pump deck. Water pressure below 40 PSI will require a booster pump.
B. Install a shut-off valve in the water line feeding the deck. If a separate water line is run for plain
water, ensure that it also has a shut-off valve.
WARNING!
Pouring coffee, tea, and like substances into the drain can cause clogging.
3
P.N. 28-0720/05
