To Next PageTo Next PageWhat causes miscellaneous leakage in my lancer Dispenser?
If you're experiencing miscellaneous leakage in your lancer Dispenser, consider the following: * Gap between parts: Tighten the appropriate retaining screws. * Damaged or improperly installed o-rings: Replace or adjust the appropriate o-rings.
Why is the soda flow insufficient in my lancer IBD 22 Dispenser?
If you're experiencing insufficient soda flow in your lancer Dispenser, it could be due to: 1. Insufficient CO supply pressure: Verify the incoming CO pressure is between 70 PSIG (0.483 MPA) and 80 PSIG (0.552 MPA). 2. The shutoff on the mounting block is not fully open: Ensure the shutoff is fully open. 3. Foreign debris in the soda flow control: Remove the soda flow control from the valve and clean out any foreign material to ensure smooth spool movement.
How to fix insufficient water flow in lancer IBD 22 Dispenser?
If you're getting insufficient water flow from your lancer Dispenser, consider the following: * Insufficient incoming supply pressure: Verify the incoming supply water pressure to the plain water inlet is a minimum of 50 PSI (0.345 MPA) and a maximum of 100 PSI (0.689 MPA). * Shutoff on mounting block not fully open: Open the shutoff fully. * Foreign debris in water flow control: Remove the water flow control from the valve and clean out any foreign material to ensure smooth spool movement. * Water filtration problem: Service the water system as required.
Why is my lancer IBD 22 Dispenser producing low or no carbonation?
If your lancer Dispenser has low or no carbonation, check the following: * Low or no CO: Check the CO supply. * Low water pressure: A water booster kit might be needed. * Worn or defective carbonator pump: Consider replacing the carbonator pump. * Backflow preventer not allowing water to flow: Replace the backflow preventer, noting the flow direction arrow from pump to coldplate. * Probe malfunctioning: Replace the probe. * PCB malfunctioning: Replace the PCB.
How to stop excessive foaming in lancer Dispenser drinks?
To address excessive foaming in drinks from your lancer Dispenser, consider these points: * No ice in bin: Fill the bin with ice and allow the coldplate to re-stabilize. * Incoming water or syrup temperature too high: Correct this prior to the dispenser. * CO pressure too high: Adjust the CO pressure downward, but not less than 70 PSI (0.483 MPA). * Water flow rate too high: Re-adjust and reset the ratio. * Nozzle and diffuser not clean: Remove and clean them. * Air in BIB lines: Bleed air from the BIB lines.
What causes water leakage around the nozzle of my lancer Dispenser?
If you're experiencing water leakage around the nozzle of your lancer Dispenser, it could be due to: * Damaged or improperly installed o-ring on nozzle: If damaged, replace. If improperly installed, adjust.
What to do if the valve will not shut off on my lancer Dispenser?
If the valve on your lancer Dispenser won't shut off, try the following: * Debris in paddle arms: Activate the valve a few times to free debris. Clean out any foreign material. * Solenoid plunger sticking: Replace the solenoid coil.
Why does the BIB pump continue to run when the syrup bag is empty on my lancer IBD 22 Dispenser?
If the BIB pump continues to run after the bag is empty in your lancer Dispenser, it could be due to: * Leak in suction line: Check the BIB connector, if still leaking then replace the line. * Leaking o-ring on pump inlet fitting: Replace the o-ring. * Defective syrup BIB pump: Replace the defective pump.
Why does my lancer Dispenser have an erratic ratio?
An erratic ratio in your lancer Dispenser could be due to: * Incoming water and/or syrup supply not at minimum flowing pressure: Check pressure and adjust. * Foreign debris in water and/or syrup flow control: Remove flow control from suspected valve and clean out any foreign material to ensure smooth spool movement. * CO regulator malfunction: Repair or replace CO regulator.
Why is my lancer Dispenser dispensing syrup and CO gas, but no water?
If your lancer Dispenser is dispensing syrup and CO gas, but no water, consider the following possible causes: * Improper water flow to dispenser: Check for water flow to dispenser. * Carbonator pump motor has timed out: Reset by turning the unit OFF, then ON by using the circuit breaker on the power supply or momentarily unplugging unit. * Liquid level probe not connected properly to PCB: Check connections of liquid level probe to PCB assembly. * Defective PCB assembly: Replace PCB assembly. * Defective liquid level probe: Replace liquid level probe. * Weak or defective carbonator pump: Replace pump.
