Connecting to Syrup Supply - Figal Syrup Tank
1. Connect tubing routed from CO
2
inlet in dispenser to gal
syrup tank CO
2
inlet.
2. Using tubing cutters, cut line from CO
2
inlet to gal syrup
tank and install tee tting, then route appropriate tubing
from second gal syrup CO
2
inlet to tee tting.
5. Route appropriate tubing from CO
2
supply to tee tting
between dispenser CO
2
inlet and gal syrup tanks and
connect tubing to tee tting.
6. Connect tubing from dispenser syrup inlet to the gal syrup
outlet tting. Repeat for each syrup line/tank.
A
B
C
D
A. Tee Fitting
B. Line to Dispenser
C. Line to First Figal Tank
D. Line to Second Figal Tank
E. Fitting
E
A
B
C
A. Figal Connector
B. Line From CO
2
Inlet
C. Oetiker Pliers
A
B
C
A. Figal Connector
B. Figal Container
C. Syrup Line
A
B
C
A. Tee Fitting
B. Line to Tee at Figal Tank
C. Dispenser CO
2
Inlet
D. CO
2
Supply
D
3. Repeat step 2 for remaining gal syrup tanks.
4. Cut tubing from dispenser CO
2
inlet to tee tting at gal
syrup tanks and install another tee tting.
