lancer DELTA III 9100 Series

Questions and Answers

D
Deborah SawyerSep 9, 2025
What to do if the BIB pump on my lancer DELTA III 9100 Dispenser does not operate when dispensing valve is opened?
- P
  Patrick HarperSep 9, 2025
  If the BIB pump on your Lancer Dispenser does not operate when the dispensing valve is opened, consider the following: * Check if you are out of CO2, CO2 is not turned on, or CO2 pressure is low. Replace the CO2 supply, turn on the CO2 supply, or adjust the CO2 pressure to 70-80 PSI. * Check if you are out of syrup. Replace the syrup supply. * The BIB connector might not be tight. Fasten the connector tightly. * There might be kinks in the syrup or gas lines. Straighten or replace the lines.
L
Laura SmithAug 23, 2025
What to do if my Lancer Dispenser is not dispensing any product?
- S
  smithjenniferAug 23, 2025
  If your Lancer Dispenser isn't dispensing any product, it could be due to a few reasons: * Check if the electric current is reaching the electric valve. If the current is adequate, inspect the solenoid coil and switch, and replace if necessary. * Verify that the water or syrup supply is proper and adequate. Remove the valve from the mounting block, slightly open the shutoffs, and check the water and syrup supply. If there is no supply, check the dispenser for freeze-up or other problems. * The transformer might have failed. Reset the transformer circuit breaker.
P
Patrick BenjaminAug 25, 2025
What to do if the compressor on my lancer DELTA III 9100 does not start (no hum), but condenser fan motor runs?
- V
  Victor MaxwellAug 26, 2025
  If the compressor on your Lancer Dispenser isn't starting (no hum), but the condenser fan motor is running, consider the following: * The compressor relay or overload might be malfunctioning. Replace the compressor relay or overload. * There might be inadequate voltage. Measure the voltage across the common and run terminal on the compressor; it must not drop below 90% of the rated voltage. * There could be incorrect wiring. Refer to the wiring diagram and correct it. * The compressor might be malfunctioning. Replace the compressor.
T
Tracy FarleyAug 26, 2025
Why is my lancer DELTA III 9100 Dispenser dispensing water only or syrup only?
- J
  Joanna AlvarezAug 27, 2025
  If your Lancer Dispenser is dispensing only water or only syrup, consider the following: * The BIB supply might be too far from the dispenser. Ensure the BIB supply is within six (6) feet of the dispenser. * The CO2 pressure might be too low. Check the CO2 pressure to the pump manifold to ensure it is between 70-80 PSI. * The BIB pump might be stalled or inoperative. Check the CO2 pressure and/or replace the pump. * There might be a kinked line. Remove the kink or replace the line.
M
mackenzie06Aug 28, 2025
What to do if my lancer DELTA III 9100 compressor starts and runs a short time, but shuts off on overload?
- B
  Bryan JohnsonAug 28, 2025
  If your Lancer Dispenser compressor starts and runs briefly before shutting off on overload, consider these potential causes: * The condenser might be dirty. Clean the condenser. * There may be insufficient or blocked airflow. Remove all obstructions and ensure minimum clearances of eight (8) inches (20.3 cm) over the top. * There could be inadequate voltage. Measure the voltage across the common and run terminal on the compressor, ensuring it doesn't drop below 90% of the rated voltage. * Incorrect wiring. Refer to the wiring diagram and correct it. * A defective condenser fan motor. Replace the condenser fan motor. * Refrigerant leak. Repair and recharge. * Compressor malfunctioning. Replace the compressor.
J
james22Aug 29, 2025
Why does the compressor on my lancer DELTA III 9100 start, but not switch off start winding?
- C
  Chelsea GarciaAug 29, 2025
  If the compressor on your Lancer Dispenser starts but doesn't switch off the start winding, running only for a few seconds before the internal overload switches it off, it could be due to: * Inadequate voltage. Measure the voltage across the common and run terminal on the compressor. * Incorrect wiring. Refer to the wiring diagram and correct it. * A malfunctioning starting relay. Replace the starting relay, ensuring you use the correct relay to prevent compressor failure.
T
Tyler HallSep 18, 2025
What causes the BIB pump on my Lancer Dispenser to continue to operate when the bag is empty?
- B
  Brandon GaySep 18, 2025
  If the BIB pump continues to operate when the bag is empty on your Lancer Dispenser, it could be due to: * A leak in the suction line. Replace the line. * A leaking o-ring on the pump inlet fitting. Replace the o-ring.
R
Ruth HallSep 22, 2025
Why does the BIB pump on my lancer DELTA III 9100 Dispenser fail to restart after bag replacement?
- T
  Thomas ThompsonSep 22, 2025
  If the BIB pump fails to restart after bag replacement on your Lancer Dispenser, it may be because: * The BIB connector is not on tight. Tighten the BIB connector. * The BIB connector is stopped up. Clean out or replace the BIB connector. * There are kinks in the syrup line. Straighten or replace the line.
P
Peter HillSep 8, 2025
Why is the water line frozen on my lancer DELTA III 9100 Dispenser even though the compressor runs normally?
- W
  William RoseSep 8, 2025
  If the compressor runs normally, but the water line is frozen on your Lancer Dispenser, consider the following: * Low water level in the water bath. Add water to the water bath until water runs out of the overflow into the drip tray. * Syrup in the water bath. Drain the water from the water bath and refill with clean water. * The water cage is out of position. Reposition the water cage. * Low refrigerant charge/slow refrigerant leak. Find and repair leak. Recharge system.
E
emilyleeSep 4, 2025
How to fix insufficient water flow in my lancer DELTA III 9100 Dispenser?
- N
  Nathan MercerSep 4, 2025
  Insufficient water flow in your Lancer Dispenser may be due to: * Insufficient incoming supply water pressure. Verify the incoming supply water pressure is a minimum of 25 PSI. * Foreign debris in the water pump. Remove the water pump strainer and clean it.

Summary

DELTA III SPECIFICATIONS

DISPENSER AND INSTALLATION HIGHLIGHTS

INSTALLATION

RECEIVING

Inspect the unit upon arrival from the carrier for any visible damage.

UNPACKING

Steps for removing the unit and its components from the shipping carton.

UNPACKING INSTALLATION KITS

Inspect and prepare the installation kits for use.

SELECTING A LOCATION

Criteria for choosing an appropriate installation site for the dispenser.

MOUNTING THE DISPENSER

Procedures for permanently mounting the dispenser or installing optional legs.

FILLING UNIT WITH WATER

Instructions for filling the water bath compartment before operation.

CONNECTING TO ELECTRICAL POWER

Guidelines for safely connecting the unit to a grounded electrical power source.

CONNECTING PYTHON TO REMOTE RECIRCULATING UNIT

Connecting the python tubing to the remote recirculating unit for product delivery.

CONNECTING PYTHON TO TOWER

Connecting the python tubing from the remote unit to the dispensing tower.

CONNECTING 24 VAC POWER SUPPLY TO TOWER

Supplying 24VAC power from the remote unit to the tower valves.

CONNECTING TO WATER SUPPLY

Connecting the unit to the potable water supply, including pressure regulation.

CONNECTING THE CO2 SUPPLY

Connecting the high-pressure CO2 regulator assembly to the CO2 cylinder.

CONNECTING TO BAG-IN-BOX (BIB) SYRUP SUPPLY

Connecting BIB syrup packages to the unit's syrup pumps.

CONNECTING TO REMOTE BIB SYRUP PUMPS

Connecting syrup supply tubes to remote BIB syrup pumps.

CONNECTING TO REMOTE PRESSURIZED SYRUP SUPPLY

Connecting syrup supply tubes to remote five-gallon syrup containers.

PURGING THE CARBONATION SYSTEM

Removing air and ensuring proper function of the carbonation system.

COMPLETE INSULATION BETWEEN REMOTE UNIT AND PYTHON

Ensuring airtight insulation of tubing between the remote unit and python.

COMPLETE INSULATION BETWEEN TOWER AND PYTHON

Ensuring airtight insulation of tubing between the tower and python.

SCHEDULED MAINTENANCE

DAILY

Routine daily cleaning of the unit's exterior surfaces.

WEEKLY

Checking and replenishing water level in the water bath.

MONTHLY

Cleaning the unit's condenser using a soft brush.

EVERY SIX (6) MONTHS

Performing cleaning and sanitizing procedures as outlined in Section 3.

YEARLY

Cleaning the water bath interior and exterior of the unit.

DISPENSER CLEANING AND SANITIZING

AMBIENT PROCESS

Standard method for cleaning and sanitizing dispenser equipment using specific solutions.

ALTERNATE CLEANING AND SANITIZING AGENTS

Approved alternative cleaning and sanitizing agents and their usage.

CONVERTING FROM EXTERNAL PRESSURIZED SYRUP SUPPLY TO BIB WITH BUILT-IN SYRUP PUMPS

CONVERTING FROM BUILT-IN SYRUP PUMPS TO REMOTE PUMPS OR SYRUP TANKS

REMOVING EXISTING BUILT-IN SYRUP PUMPS

Steps to safely disconnect and remove the unit's built-in syrup pumps.

INSTALLING REMOTE PUMP OR SYRUP TANKS

Procedures for installing remote syrup pumps or syrup tanks.

CONNECTION FOR PLAIN WATER PRODUCT

Connecting the plain water line to the dispenser.

TROUBLESHOOTING

MISCELLANEOUS LEAKAGE

Identifying causes and remedies for various types of leaks within the unit.

INSUFFICIENT WATER FLOW

Diagnosing and fixing issues related to low or inadequate water flow.

INSUFFICIENT SYRUP FLOW

Troubleshooting problems with low or inconsistent syrup delivery.

ERRATIC PRODUCT RATIO

Addressing issues where the water-to-syrup ratio is incorrect.

NO PRODUCT DISPENSED

Identifying reasons for complete failure to dispense any product.

WATER OR SYRUP ONLY DISPENSING

Diagnosing issues causing only water or only syrup to dispense.

NO WATER, JUST SYRUP (ICE BANK ISSUE)

Resolving problems where the ice bank interferes with water supply.

SYRUP ONLY, NO WATER, WITH CO2

Troubleshooting dispensing issues involving syrup, CO2, but no water.

EXCESSIVE BEVERAGE FOAMING

Addressing causes and solutions for drinks dispensing with too much foam.

WATER OVERFLOW INTO DRIP TRAY

Diagnosing and fixing problems causing water to overflow into the drip tray.

COMPRESSOR RUNS CONTINUOUSLY

Troubleshooting compressor running continuously without shutting off.

WARM BEVERAGE DISPENSING

Identifying causes for dispensing warm beverages instead of cold.

COMPRESSOR & FAN FAIL TO START

Diagnosing issues where the compressor and fan do not start.

COMPRESSOR FAILS TO START, FAN RUNS

Troubleshooting when the compressor doesn't start but the fan runs.

COMPRESSOR HUMS, FAILS TO START

Diagnosing issues where the compressor hums but does not start.

COMPRESSOR START WINDING ISSUE

Resolving compressor start-up issues where it shuts off quickly.

COMPRESSOR OVERLOAD SHUTDOWN

Troubleshooting compressor shutting off due to overload conditions.

FROZEN WATER LINE

Diagnosing why the water line freezes while the compressor runs normally.

FREQUENT COMPRESSOR CYCLING

Addressing frequent cycling of the compressor during start-up or operation.

CIRCUIT BREAKER TRIPPING

Identifying causes for the circuit breaker tripping repeatedly.

BIB PUMP FAILS TO OPERATE

Troubleshooting BIB pump failure to operate upon dispensing.

BIB PUMP OPERATES, NO FLOW

Diagnosing BIB pump operation without product flow.

BIB PUMP OPERATES WHEN EMPTY

Resolving issues where the BIB pump runs after the syrup bag is empty.

BIB PUMP FAILS TO RESTART AFTER BAG CHANGE

Troubleshooting BIB pump failure to resume operation after a bag change.

BIB PUMP FAILS TO STOP

Fixing BIB pump issues where it does not stop after valve closure.

LOW OR NO CARBONATION

Diagnosing and resolving problems with insufficient or no carbonation.

ILLUSTRATIONS, PARTS LISTINGS, AND WIRING DIAGRAMS

REFRIGERATION DECK ASSEMBLY

Diagram and parts list for the refrigeration deck components.

CABINET ASSEMBLY

Diagram and parts list for the main cabinet structure and components.

CARBONATOR DECK;PUMP BRACKET ASSEMBLY

Diagram and parts list for the carbonator deck and pump mounting.

CARBONATOR WATER;SYRUP LINE ASSEMBLIES

Diagrams and parts lists for water and syrup line configurations.

CONTROL HOUSING

Diagram and parts list for the control housing and its components.

REGULATOR WATER ASSEMBLY

Diagram and parts list for the water pressure regulator assembly.

WIRING DIAGRAM - DELTA III

Electrical schematic illustrating the unit's wiring connections and components.

lancer DELTA III 9100 Series Specifications

General

Category	Dispenser
Brand	Lancer
Series	DELTA III 9100 Series
Model	9100 Series
Material	Stainless Steel
Power Source	Electric
Dispensing Mechanism	Lever or Push Button
