4
SPECIFICATIONS AND FEATURES
This unit emits a sound pressure level below 70 dB
DIMENSIONS
Width: 30.0 inches (762 mm)
Depth: 31.0 inches (787 mm)
Height: 37.25 inches (946 mm)
WEIGHT
Shipping: 335 lbs (152.0 kg)
Empty: 275 lbs (125.0 kg)
Ice Capacity: 250 lbs (113.6 kg)
Ice Dispensable: 185 lbs (84.0 kg)
ELECTRICAL
115 VAC / 60 Hz / 3.0 Amps
PLAIN WATER SUPPLY
Min Flowing Pressure: 75 PSIG (0.516 MPA
CARBONATED WATER SUPPLY
Min Flowing Pressure: 25 PSI (0.172 MPA)
Max Static Pressure: 50 PSI (0.345 MPA)
CARBON DIOXIDE (CO
2
) SUPPLY
Min Pressure: 70 PSIG (0.483 MPA)
Max Pressure: 80 PSIG (0.552 MPA)
FITTINGS
Carbonator Inlet: 3/8 inch barb
Plain Water Inlet: 3/8 inch barb
Brand Syrup Inlets: 3/8 inch barb
• Units are equipped with an automatic agitation system and will activate unexpectedly.
• CAUTION: Do not place hands or foreign objects in the ice bin tank. Unplug the dispenser during servicing, cleaning, and
sanitizing.
• CAUTION: To avoid personal injury, do not attempt to lift the dispenser without assistance. For heavier dispensers, use a
mechanical lift.
! Automatic Agitation
30"
762mm
36" W/O LID
915mm
23.5"
596.9mm
31"
787mm
9½"
241mm
37¼"
946mm
A. Merchandiser
B. Valves
C. Splash Plate
D. Drip Tray
E. Cup Rest
A
B
C
E
D
