40
Frame - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.921-387.0 1 PANEL SUPPORT, TOP COIL
2 8.921-386.0 1 PANEL SUPPORT, TOP PUMP
3 8.921-389.0 6 BRACKET, DOOR LATCH
4 8.753-398.0 12 RIVET, 3/16 LPST
5 8.718-625.0 25 BOLT, 5/16-18 X 3/4 CRRG
6 9.802-778.0 12 NUT, 5/16" WHIZ LOC
7 8.925-209.0 1 ASSY, PUMP RAIL, NG/SM
8 8.753-397.0 81 RIVET, 1/4" PRST
9 8.920-696.0 1 BASE PLATE, COIL NG/SM
10 8.921-406.0 4 POST, FRAME, NG/SM
11 8.921-407.0 2 RAIL, COIL/PUMP NG/SM
12 8.921-394.0 1 BRACKET, PUMP/COIL CENTER
Landa ENG Dealer’s Manual 9.801-510.0 - AV
