41Landa ENG Dealer’s Manual 9.801-510.0 - AV
Frame - NG 4-5
NG 4-2000, 4-2200, 4-3000, 5-2300, 5-3000
REF PART NO. QTY DESCRIPTION NOTES
13 8.921-404.0 1 POST, CENTER, FRONT, NG/SM
14 8.921-405.0 1 POST, CENTER, REAR, NG/SM
15 9.802-778.0 4 NUT, 5/16" WHIZ LOC
- 9.802-781.0 4 NUT, 3/8" WHIZ LOC
16 8.718-625.0 4 BOLT, 5/16"-18 X 3/4" CRRG
- 8.753-546.0 4 BOLT, 3/8" X 1" CRRG
17 8.718-873.0 8 NUT, RETAINER, 5/16"
- 8.751-125.0 5 NUT, RETAINER, 3/8"
18 8.920-699.0 1 PLATE, MOTOR, NG/SM
19 8.706-547.0 12 GROMMET, 1/2"X 1"X 1/2"
20 8.921-385.0 1 MIRROR
21 8.921-383.0 1 BASE, NG/SM
22 8.706-534.0 3 GROMMET, 2" RUBBER
23 8.802-103.0 1 BUSHING, 5/8" SNAP
