48
Frame - NG 6-10
NG 6-3200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.921-642.0 1 PANEL, SUPPORT, TOP, COIL SIDE, NG/LM
2 8.921-643.0 1 PANEL, SUPPORT, TOP, PUMP SIDE, NG/LM
3 8.921-389.0 6 BRACKET, DOOR LATCH, NG/LM
4 8.753-398.0 19 RIVET, 3/16" LPST
5 8.718-625.0 25 BOLT, 5/16' X 18 X 3/4', NC CRRGE ANC (6159)
6 9.802-778.0 12 NUT, 5/16" WHIZ LOC FLANGE
7 8.923-701.0 1 RAIL, PUMP, NG/LM
8 8.753-397.0 103 RIVET, 1/4" PRST
9 8.921-632.0 2 RAIL, COIL/PUMP, NG/LM
10 8.921-629.0 4 POST, FRAME, NG/LM
11 8.921-641.0 1 BASE PLATE, COIL, NG/LM
12 8.921-633.0 1 BRACKET, PUMP/COIL, CENTER NG/LM
13 8.921-630.0 1 POST, CENTER, FRONT, NG/LM
Landa ENG Dealer’s Manual 9.801-510.0 - AV
