49Landa ENG Dealer’s Manual 9.801-510.0 - AV
Frame - NG 6-10
NG 6-3200, 8-3200, 10-3000
REF PART NO. QTY DESCRIPTION NOTES
14 8.921-631.0 1 POST, CENTER, REAR, NG/LM
15 9.802-781.0 10 NUT, 3/8" NC, WHIZ LOC FLANGE
16 8.753-546.0 4 BOLT, 3/8- 16 X 1" CARRIAGE ZNC
17 8.751-125.0 5 NUT, 3/8 PUSH, BOLT RETAINER
18 8.921-651.0 1 PLATE, MOTOR, NG/LM
19 8.706-547.0 12 GROMMET, 1/2' X 1' X 1/2
20 8.921-385.0 1 MIRROR
21 8.921-627.0 1 BASE, HALF, FRONT, NG/LM
22 8.706-534.0 2 GROMMET, 2"RUBBER, WATER BLASTER
23 8.921-628.0 1 SUPPORT, BASE, NG/LM
24 8.921-626.0 2 BASE, HALF, REAR, NG/LM
25 8.912-530.0 2 ASSY, PLATE, DISCHARGE COUPLING, VNG
26 9.802-103.0 1 BUSHING, 5/8" SNAP
