73Landa ENG Dealer’s Manual 9.801-510.0 - AV
Electrical Box - NG 6-10
NG 6-3200, 8-3200,10-3000
REF PART NO. QTY DESCRIPTION NOTES
1 8.921-637.0 1 FACE PLATE, ELEC BOX, NG/LM
2 8.753-398.0 4 RIVET, 3/16" LPST
3 8.921-638.0 1 BOX, ELECTRICAL, NG/LM
4 8.753-255.0 4 NUT, EXTRUDED U-NUT, 1/4"-20
5 8.753-364.0 1 STRAIN RELIEF, LT, 1" NPT, BLACK
6 9.802-515.0 1 STRAIN RELIEF, 1/2"
7 8.706-755.0 1 BUSHING, .875, P/N 2119
8 8.921-639.0 1 COVER, ELECTRICAL BOX, REAR, NG/LM
9 8.726-103.0 4 SCREW, 1/4" X 20 5/8", WHIZ LOC BLK CAD
10 8.716-883.0 1 TRANSFORMER, 208/230/460-V-24/ 115V, .050KVA
- 8.716-884.0 1 TRANSFORMER, 100KVA, 575-24 W/FUSE BLOCK (575V Models)
11 9.802-759.0 8 SCREW, 10/32" X 1/2" BH SOC BLK
12 9.802-695.0 25 NUT, 10/32" KEPS
13 8.749-980.0 2 TERMINAL BLOCK, END CAP, PHOENIX
14 8.749-976.0 8 TERMINAL BLOCK, FEED-THRU, PHOENIX
15 9.804-595.0 2 END BRACKET, ENTRELEC 103-002-26
16 8.753-064.0 4 TERMINAL, BLOCK, IDC
17 9.802-457.0 7" DIN RAIL, 35MM
18 9.802-457.0 2-1/2" DIN RAIL, 35MM
19 8.724-280.0 1 CONTACTOR, DP C25DNY154AL, 40 AMP
(6-3200C,F), (8-3200C,F),
(10-3000C,F)
- 8.724-283.0 1 CONTACTOR, DP C25DNY155TL, 50 AMP
(6-3200B,H), (8-3200B),
10-3000B)
- 8.753-798.0 1 CONTACTOR, DP C25FNF360T, 60 AMP (8-3200H), (10-3000H)
20 8.724-304.0 1 OVERLOAD, XTOB040DC1DP, 16.0-24.0
(6-3200C,F), (8-3200F),
(10-3000F)
- 8.724-305.0 1 OVERLOAD, XTOB032CC1DP,24.0-40.0 (8-3200C), (10-3000)
- 8.724-307.0 1 OVERLOAD, XTOB057DC1DP,40.0-57.0
(6-3200B,H) (8-
3200B),(10-3000B)
- 8.753-799.0 1 OVERLOAD, C440BIA100SDF, 20-100 AMP (8-3200H), (10-3000H)
21 8.716-086.0 1 RELAY, 24V DPST NO
22 9.803-613.0 1 MODULE, IGNITION, ELECTRONIC, HONEYWELL
