74
Electrical Box - NG 6-10
NG 6-3200, 8-3200,10-3000
REF PART NO. QTY DESCRIPTION NOTES
23 8.718-755.0 2 SCREW, 8/32" X 1-1/2"
24 8.749-977.0 5 BAR, JUMPER, PHOENIX FBS 2-5GY
25 8.749-743.0 1 FUSE, 4-AMP
26 8.713-080.0 2 FUSE, CLASS R 1 AMP (208/230 1PH & 3PH)
- 8.713-081.0 2 FUSE, CLASS R 1/2 AMP (460/575 3PH)
27 8.718-730.0 1 SCREW, 10/32" X 2-1/2" RND HD MCH
28 8.900-207.0 1 LABEL, INCOMING POWER
29 8.716-460.0 1 TERMINAL, GROUNDING LUG LAMA6-14-Q
30 8.753-544.0 1 TERMINAL, BLOCK, 3-POLE, 85 AMP
31 9.800-040.0 2 LABEL, GROUND SYMBOL
Landa ENG Dealer’s Manual 9.801-510.0 - AV
