The load-bearing and moving parts must be checked before each use to ensure that they are in perfect condition.
Damaged parts must be replaced immediately with faultless parts. In the event of damage or faults,
please directly contact
LANG Technik GmbH • Albstraße 1–6 • D-73271 Holzmaden • Phone: +49 7023 9585-0
5.2
The Makro•Grip
®
(FS) 5-Axis Vise is supplied without lubrication points.
5.3
Before each use of the product Visual inspection for condition and function
During operation Regular visual inspection for contamination
After each operation Manual or automated cleaning
5.4
Tools required:
Torque wrench (up to at least 50 Nm)
Allen wrench (various wrench sizes - internal and external hexagon)
Base body
width of vise
Torque wrench (size) Allen wrench (size)
Tightening torque for
mounting bolt [Nm]
46 8 3; 4; 6 40
77 12 4; 5; 6 40
125 15 5; 8 50
5.5
5.5.1
1. Remove the clamping jaws (item 3 in 1.2 Assembly). See point 4.2.
2. Remove the threaded spindle + center piece set (item 2 in 1.2 Assembly). To do this, the two countersunk
screws on the underside of the base body must be removed.
3. Remove Quick•Point
®
clamping studs (item 4 in 1.2 Assembly)
5.5.2
With one exception, assembly is carried out in the reverse order. The exception is the insertion of the clamping
jaws. The procedure is described in section 4.2.2.
