Chapter 5 Chapter 6
5.6
Spare parts may be required for the maintenance and repair of the Makro•Grip
®
(FS) 5-Axis Vise. Information that
you should have ready for ordering spare parts from the manufacturer LANG Technik GmbH is as follows:
Designation of the Makro•Grip
®
(FS) 5-Axis Vise
Article number (item no.)
Designation of the spare part
Order quantity
6
6.1
If clamping devices are repaired or replaced incorrectly, parts of the product or workpiece may come
loose and cause injury or damage.
Repair and replacement work on the product may only be carried out by trained and instructed personnel who
have also been trained and instructed in the operation of the machine tool.
Carry out maintenance and care work outside the machine tool. Before starting the uninstallation/installa-
tion, switch off the machine tool and secure the machine against being switched on again (see machine tool
operating instructions).
After completing maintenance and repair work, make sure that any safety equipment on the machine tool
that may have been removed has been restored (such as protective covers,...).
Damage and defects to the product must be reported to the operator immediately and repaired by qualified
personnel without delay in order to minimize the extent of the damage and not impair the safety of the
product.
Pos. Malfunction Description
Drop in clamping force Clamping jaws or stamping jaws damaged
or worn.
Check clamping jaws or stamping jaws, clean
and replace if necessary
Centering accuracy not
given
Serial number of the clamping jaws not
identical
Insert clamping jaws with the same serial
number
Clamping jaw jams in the
guide
Contact surfaces dirty or damaged Check clamping jaws and base body, clean,
replace if necessary
5-Axis Vise jams Zero point plate dirty, damaged or worn Dismantle, check and clean the zero point
plate, replace wedges if necessary
5-Axis Vise is not pushed
upwards when the plate
is opened
Plastic nipple of the zero point plate
damaged or missing
Replace plastic nipple
