① Base body made of case-hardened steel
② Threaded spindle including center piece
③ Clamping jaws with holding serration
NOTE
The serial number of the two clamping jaws must always be identical!
④ Quick•Point
®
clamping studs / integrated zero point interface
1.3
Complete 5-Axis Vise included
mounted Makro•Grip
®
clamping jaws with holding teeth on both sides and
Four (or two) Quick•Point
®
52 or 96 clamping studs
Operating instructions
