6
1
1.6
®
Item no. For 5-Axis Vise size Size
45510 External hexagon 46 SW 8
45500 External hexagon 77 SW 12
45501 External hexagon 125 SW 15
45515 Allen key 46 SW 4
45505 Allen key 77/ 125 SW 5
Item no. Drive square 5-Axis Vise size Size
45508 3/8“ 77 SW 12
45509 3/8“ 125 SW 15
Item no. For
47005 Allen key SW5
1.7
1.7.1
A tungsten carbide coating can be subsequently applied to the smooth surfaces of the Makro•Grip
®
(FS) clamping
jaws to further increase the holding force when smoothly clamping non-stamped workpieces. The coating is
always applied to a pair of clamping jaws.
1.7.2
The holding serration of the clamping jaws can be milled off on request. Please note, however, that the actual
case-hardened contact point to the workpiece will then be soft. In this case, we offer case-hardened clamping
jaws without holding serration. Information on this can be found on our website www .lang-technik.de.
Order no. Jaw width
45046-17 46 mm
45077-17 77 mm
45125-17 125 mm
