Item no. Description Jaw width Base length Spindle Spindle length Clamping range
48040-46 FS
Makro•Grip® F S 46
micro
46 mm 77 mm Ø 12 mm x 1,0 82 mm 0 - 65 mm 2
48065-46 FS Makro•Grip® F S 46 46 mm 77 mm Ø 12 mm x 1,0 82 mm 0 - 65 mm 4
4808 5-46 FS Makro•Grip® F S 77 46 mm 102 mm Ø 16 mm x 1,5 100 mm 0 - 85 mm 4
48120-46 FS Makro•Grip® F S 77 46 mm 130 mm Ø 16 mm x 1,5 135 mm 0 - 120 mm 4
4808 5-77 FS Makro•Grip® F S 77 77 mm 102 mm Ø 16 mm x 1,5 100 mm 0 - 85 mm 4
48120-77 FS Makro•Grip® F S 77 77 mm 130 mm Ø 16 mm x 1,5 135 mm 0 - 120 mm 4
68120-77 FS
Makro•Grip® F S 77
Night King
77 mm 130 mm Ø 16 mm x 1,5 135 mm 0 - 120 mm 4
48160-77 FS Makro•Grip® F S 77 77 mm 170 mm Ø 16 mm x 1,5 175 mm 0 - 160 mm 4
48200-77 FS Makro•Grip® F S 77 77 mm 210 mm Ø 16 mm x 1,5 215 mm 0 - 200 mm 4
48155-77 FS Makro•Grip® F S 125 77 mm 160 mm Ø 20 mm x 1,5 164 mm 0 - 155 mm 4
48205-77 FS Makro•Grip® F S 125 77 mm 210 mm Ø 20 mm x 1,5 214 mm 0 - 205 mm 4
48155-125 FS Makro•Grip® F S 125 125 mm 160 mm Ø 20 mm x 1,5 164 mm 0 - 155 mm 4
48205-125 FS Makro•Grip® F S 125 125 mm 210 mm Ø 20 mm x 1,5 214 mm 0 - 205 mm 4
48255-125 FS Makro•Grip® F S 125 125 mm 260 mm Ø 20 mm x 1,5 264 mm 0 - 255 mm 4
48305-125 FS Makro•Grip® F S 125 125 mm 310 mm Ø 20 mm x 1,5 314 mm 0 - 305 mm 4
48355-125 FS Makro•Grip® F S 125 125 mm 360 mm Ø 20 mm x 1,5 364 mm 0 - 355 mm 4
NOTE
The interfering contours and general properties of the 5-Axis Vise (apart from the holding serration) are identical in the same
vise size in both series (e.g. 48120-77 to 48120-77 FS). Spare parts and accessories, such as threaded spindles, are therefore
compatible in both series.
1.5.2
®
Item no. Jaw width for vise type
48046-4620 46 mm 48040-46 micro, 48065-46
48077-4620 46 mm 48120-46
48085-4620 46 mm 48085-46
48077-7720 77 mm 48120-77, 48160-77, 48200-77
48085-7720 77 mm 48085-77
48125-7720 77 mm 48155-77, 48205-77
48125-2520 125 mm
all Makro•Grip
®
125 with
jaw width 125 mm
NOTE
Other clamping solutions, such as center jaws for multiple clamping or clamping jaws without holding serration, are also inclu-
ded in the product range. Information on this can be found in the current catalog and on the website www .lang-technik.de.
Item no. Jaw width for vise type
48046-4620 FS 46 mm 48040-46 FS micro, 48065-46 FS
48077-4620 FS 46 mm 48120-46 FS
48085-4620 FS 46 mm 4808 5-46 FS
48077-7720 FS 77 mm 48120-77 FS, 48160-77 FS, 48200- 77 FS
4808 5-7720 FS 77 mm 4808 5-77 FS
48125-7720 FS 77 mm 48155-77 FS, 48205-77 FS
48125-2520 FS 125 mm
all Makro•Grip
®
FS 125 with
jaw width 125 mm
