JRESET1 : Select front-panel reset option
1-2 Hardware Reset
2-3 Software Reset (Default)
JSATA1/JSATA2 : SATA connectors for storage devices
PIN
DESCRIPTION
1
BTN_SYS_RESET#
2
FP_RESET#
3
SW_RST_GP5#
