Larius Jolly - Technical Data

Ediz. 010 - 06/2015
SUPPLY (single-phase)*
MOTORDRIVE SUPPLY
MOTOR POWER
MAX WORKING PRESSURE
MAX. DELIVERY
MATERIAL OUTLET
MA. DIMENSION OF THE GUN NOZZLE
WEIGHT
SOUND PRESSURE LEVEL
LENGTH
WIDTH
HEIGHT
230Vac - 50Hz
min. 4Kw
asynchronous
0,65 kW
210 bar
1,8 L/min
M16 x 1,5 (M)
0,019”
15 Kg
≤ 80dB(A)
(A) 450 mm
(B) 460 mm
(C) 550 mm
TECHNICAL DATA
JOLLY
230Vac - 50Hz
min. 4Kw
asynchronous
0,65 kW
210 bar
1,8 L/min
M16 x 1,5 (M)
0,019”
16 Kg
≤ 80dB(A)
(A) 580 mm
(B) 540 mm
(C) 995 mm
B
*Available on request with special voltages
PARTS OF THE PUMP IN CONTACT WITH THE MATERIAL Stainless Steel AISI 420B, PTFE, Aluminium
www.larius.eu
JOLLY
4
Version on
FRAME
Version
on TROLLEY
Version on TROLLEY
Version on FRAME
B
A
C
C
A
B
