Larius Jolly - Recirculating-Safety Valve Group; Ref. 56563

Ediz. 010 - 06/2015
Pos. Code Description
- 56563 Recirculating-safety valve group
1 4033 OR 2062
2 16415 Valve housing
3 53007/3 OR 2018
4 16419 Ring BK 2018
5 16420 Complete rod
6 16410 Spring
7 16409 Clamping ring
8 16408 Pin
9 16405 Knob
Q
RECIRCULATING-SAFETY VALVE GROUP REF. 56563
FOR ALL VERSIONS
www.larius.eu
JOLLY
32
1
2
3
45
7
8
9
6
WARNING: Always indicate code and quantity for each part required.
