Larius Jolly - Complete Electro-Hydraulic Group

Ediz. 010 - 06/2015
Equipped with:
MATERIAL HOSE 1/4" - M16x1,5
Art. 18007: 15 mt
For a 1/4” fitted gun, you need:
ADAPTER
Art. 3276
Pos. Pos.Code CodiceDescrizione Descrizione
0 56561 Complete electro-hydraulic group
1 56533 Electro-hydraulic box
2 56532 Box cover
3 18625 Gasket
4 56563 Valve
5 56530 Electronic card
6 56534 Filter cap
7 16205 Filter sieve
8 18627 Sieve support
9 56535 Gasket
10 96206 Fitting
11 18614 Fitting
12 5933 Switch
13 95210 Dowel
14 18684 Gasket
15 18692 Pressure sensor
16 18693 Potentiometer
17 18682 Plug
18 18687 Pressure label
19 18871 Cable fastener
20 18870 Power cable
21 96208/1 Fitting
22 18694 Adjusting knob
23 5737 Washer
24 4019 Screw
25 18657 Pressure label
26 34020 Rivet
27 5727 Screw M6x8
28 54004 Screw M6x16
29 32005 Rondella ø6
