Larius Jolly - Ucomplete Hydraulic Group

Ediz. 010 - 06/2015
COMPLETE HYDRAULIC GROUP REF. 56562 FOR ALL VERSIONS
U
0 56562 Complete hydraulic group
1 16109 Ring packing
2 16127 Locking nut
3 16105 Upper gaskets kit
4 96208/1 Fitting
5 18640 Sleeve
6 16126 OR 2112
7 18642 Ball guide
8 16120 Ball
9 91018 Ball housing
10 18675 Seal
11 56536 Foot valve body
12 18553 OR 2012
13 56540 Disk
14 9288 Spring
15 56547 Releasing rod
16 56538 Guiding bushing
17 56541 Rod rubber
18 18652 Piston rod
19 16130 Ball
20 18651 Lower gaskets kit
21 18648 Scraper ring
22 18655 Complete rod valve
Pos. Pos.Code CodeDescription Description
www.larius.eu
JOLLY
37
1
2
4
5
6
7
8
9
10
12
13
15
16
17
11
23
18
19
21
22
3
14
20
COMPLETE CONNECTION TUBE
REF. 18790
COMPLETE HYDRAULIC ROD
REF. 18650
COMPLETE HYDRAULIC SLEEVE
REF. 56565
WARNING: Always indicate code and quantity for each part required.
