• Lift the suction group and dip it into the tank containing the
washing liquid.
• Press the equipment main switch (F5) on pos. “ON” (I).
• Open the recirculation-safety valve (F7).
CONNECTING THE EQUIPMENT TO THE POWER SUPPLY
• Check that the switch (F5) is on the “OFF” (0) position
before connecting the cable to the mains.
• Place the pressure control knob (F6) on the “MIN” position
(turn counterclockwise).
WASHING OF THE NEW EQUIPMENT
• Theequipmenthasalreadybeenadjustedatourfactorywith
light mineral oil left inside the pumping group as protection.
Therefore, wash with diluent before sucking the product.
• Ensurethegun(F3) is without nozzle.
www.larius.eu
JOLLY
10
OFF
F5
F6
ON
F5
F6
F3
F7F7
F7
OPEN
It re-circulates back into
the tank without spraying
CLOSED
It sprays out of
the spray gun
