MIN MAX
PRESSIONE
PRESSURE
Ediz. 010 - 06/2015
• Open the recirculating-safety valve (G2) (turn clockwise so
as the pin slides on the cam track).
OPEN
It re-circulates back into
the tank without spraying
CLOSED
It sprays out of
the spray gun
• Close the recirculating-safety valve (G2) (turn clockwise to
release the valve).
• Press the switch “ON” (I) of the equipment and turn slightly
the pressure control knob clockwise (G3), so as the machine
works at the idle speed.
• The machine will continue to suck the product till the flexible
hose is full up to the set pressure.
Then it will automatically stop.
• Adjust the operation pressure with the knob (G3).
• Make sure the product recycles from the recirculation tube
(G4).
www.larius.eu
JOLLY
13
G2G2
G2
G3
G2
G4
