• Remove the kit of gaskets contained inside the pump unit
housing, as shown.
• Remove the lower stainless steel male ring (P22) as shown.
• Fit the new gasket kit according to the component sequence
shown in the picture.
Upper white
PTFE
Grey polyethylene
Waxed leather
Grey polyethylene
Lower white PTFE
www.larius.eu
JOLLY
23
1
P22
2
3
4
5
