LaserPro Venus - Motion System

11
-7-
#4 Mirror Inside
Fig.3 Motion System I
Choose air exhausting direction
either from back of the table or
through the holes on working
table. Adjuster in middle position
can exhaust air both backward
and downward.
I. Dust Prevention Box (#2 Mirror
inside)
Y-axis
#3 Mirror & Holder
Release the Screw to
Pull Out the Mirror
Focal-Sharp™
II. Auto-focus
Manual Focus
Gauge Holder
X-axis
III. Y-axis
Motor
IV. Dust
Bearing Track
X-axis Motor
Air Flow Adjuster
#4 Mirror Inside
