LaserPro Venus - LENS and MANUAL FOCUS GAUGE

6
LENS and MANUAL FOCUS GAUGE
Focal Length Matched Color
LENS MANUAL FOCUS GAUGE
1.5” Standard Purple Blue (same as 2.0”)
2.0” Option Blue Blue
2.5” Option Gold Gold
Manual Focus
Gauge Holder
Insert to the hole
of the holder for
manual focusing
Mirror
Lens 2.0, 2.5
Slot position for
Lens 1.5 only
Auto Focus Gauge
Focal-Sharp™
Manual Focus Gauge
Figure of Focus Carriage
Focus Probe
NOZZLE
