Initial Set-Up
Weight Transfer Springs
3
3-12 Lastec Mower 3372/011305 Initial Set-Up
3.14 Weight Transfer Springs
It is important that the weight transfer system
is operating properly. The weight transfer
springs help to lighten the mower deck by
transferring excess weight to the drive unit.
The elimination of excess weight allows
more agile floating of the mower deck,
resulting in a higher quality cut and a lower
incidence of turf damage.
The weight transfer springs are located
under the operator seat pan, running from
the mounting bolt on the left front of the
frame to the anchor located on the pivot arm.
The pivot arm extends to the outer left and
right of the frame.
Check to be sure that all weight transfer
springs are properly mounted and secure,
both to the mounting bolt in front and back.
Proper operation of the weight transfer system will allow you to lift the mowing deck by the handle
with little effort.
Go to www.lastec.com for latest changes in this manual.
