Operating Procedures
Mule Pulley Adjustment
4
4-6 Lastec Mower 3372/011305 Operating Procedures
NOTE:
Leaving the operator seat at any time while the blades are
engaged will cause the blades to automatically disengage and the engine to stop.
4.6 Mule Pulley Adjustment
The mule pulley is located under the engine.
The drive belt passes through the pulley to
the main deck drive pulley. Under normal
operating situations, the pulley should not be
changed from the factory set position.
However, in order to help the idler pulley
keep proper tension on a drive belt (40-50
ft-lbs on the Cricket gauge [part number
028498]) that has possibly stretched, the
mule pulley may be adjusted. Simply remove
the center bolt and place the pulley at the
level most appropriate to maintain the proper
belt tension.
Belt Route
Go to www.lastec.com for latest changes in this manual.
