Lastec Articulator - Torque Values

Maintenance
Torque Values
Maintenance XR700 062419 5-3
5
Along with completing the Pre-Operation Equipment Inspection Checklist each time you
operate the Articulator, complete the following Maintenance Checklists at the indicated
time intervals.
5.2 Torque Values
Below is a table of suggested torque values for this unit. Please use these torque values
on this unit unless otherwise specified.
Grade
Units
SAE 5 SAE 8
Tensile
Strength
105000
PSI
150000
PSI
Grade Mark
Bolt
Dia.
Threads.
Per In.
Units SAE 5 SAE 8
6
8
10
10
12
1/4
1/4
5/16
5/16
3/8
3/8
7/16
7/16
1/2
1/2
9/16
9/16
5/8
5/8
3/4
3/4
7/8
7/8
1
32
32
24
32
24
20
28
18
24
16
24
14
20
13
20
12
18
11
18
10
16
9
14
8
in-lbs (Nm)
in-lbs (Nm)
in-lbs (Nm)
in-lbs (Nm)
in-lbs (Nm)
in-lbs (Nm)
in-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
ft-lbs (Nm)
20 (2.3)
24 (2.7)
35 (4.0)
40 (4.5)
50 (5.7)
95 (10.7)
95 (10.7)
17 (22.6)
20 (27.1)
30 (40.7)
35 (47.5)
50 (67.8)
55 (74.6)
75 (101.7)
85 (115.3)
105 (142.4)
115 (155.9)
150 (203.4)
160 (217.0)
170 (230.5)
175 (237.3)
302 (409.5)
300 (406.8)
466 (631.8)
-
30 (3.4)
45 (5.1)
50 (5.7)
65 (7.3)
125 (14.1)
150 (17.0)
23 (31.2)
25 (33.8)
40 (54.2)
45 (61.0)
65 (88.1)
70 (94.9)
100 (135.6)
110 (149.2)
135 (183.1)
150 (203.4)
195 (264.4)
210 (284.8)
220 (298.3)
225 (305.1)
473 (640.9)
400 (542.4)
714 (967.4)
