Articulator Specifications, XR700
Maintenance XR700 062419 5-7
5
5.11 Articulator Specifications, XR700
Mower Deck Cutting Width 11’ 0” XR700/XR700T Only
7’ 6” 521XR Only
Mower Deck Configura-
tion
(7) 21” Articulating Mower Decks
XR700/XR700T Only
Mower Deck Configura-
tion
(5) 21” Articulating Mower Decks 521XR Only
Blades XR700/XR700T
Only
(7) 21” High Lift P128
(7) 21” Low Lift P246
(7) 21” Mulching Blades P322
(7) 21” Low Lift Ultra 063265
Blades 521XR Only (5) 21” High Lift P128
(5) 21” Low Lift P246
(5) 21” Mulching Blades P322
(5) 21” Low Lift Ultra 063265
Blade Tip Speed Max 16,600 FPM
Paint Red, 12 oz spray P299
Black, 12 oz spray L07467
Mower Deck Height
Range
1” to 4 3/4”
Operating Environment Outdoor Use Only
Mower Deck Gauge
Wheels
(13) 9” x 3” Urethane-FIlled XR700/XR700T
Only
A150
(9) 9” x 3” Urethane-FIlled 521XR Only A150
Transport Tires (2) 15” x 6” Urethane-Filled 029261
Mower Deck Drive Belts Belt, Goodyear Insta-Power 85610 P450
Mower Deck Belts Belt, B60 P427
Gearbox Superior QTR500 2:1 A Rotation
(Serial #29860108 and later)
056601
Superior Model 500 Style A Rat 2:1 Modified
019540
(Prior to Serial #29860108)
P300
Gearbox Oil 28 Ounces SAE 80W-90 Grade Gear Oil
PTO Shaft Bondioli 21 1/4” 7104051FFT07S07
521XR/XR700 Only
P225-10
Bondioli 80 Deg XR700T Only 103610
