Initial Set-Up
Weight Transfer Springs
Initial Set-Up 9/27/19 3-10
3
Ensure to replace all covers and hardware.
3.13 Weight Transfer Springs
The weight transfer springs help to
lighten the mower deck by transferring
excess weight to the drive unit, allowing
more agile floating of the mower deck
and a higher quality cut.
The weight transfer springs are located
under the operator seat pan. See Figure
3-5.
Check that all weight transfer springs
are properly mounted and secure. (The
springs may come as close as one inch
to the mounting bracket.)
5. Adjust the spring tension by tightening the bolt at the rear of the springs.
Proper operation of the weight transfer system will allow you to lift the mowing deck by
the handle with little effort.
3.14 Blades
Do not inspect, adjust, change, or perform any other maintenance to
the blades while the engine is running.
Turn off the blades, turn off the engine, remove the key, and set the
parking brake before attempting to inspect, adjust, change, or perfo
rm
any other maintenance to the blades.
Do not expose yourself or others in any way to the blades while the
en
gine is running.
Keep all personnel clear of all controls while inspe
cting, adjusting,
changing, or performing maintenance to the blades.
