Integral T process thermostats
21/01/2019 / YAWE 0026 Starting up 57
Calibrating the internal Pt100 (outflow sensor)
Measure the outflow temperature with the reference
probe at the pump outlet in the liquid stream.
Press approx. 4 sec. Input the corrected value.
Calibrating the external Pt100 (external sensor)
Place the reference sensor at the location of the
external Pt100. Press approx. 4 sec. Input the
corrected value.
If no external Pt100 is connected the display shows
FAIL.
7.6.4.7 Base settings (DEFAULT)
Pressing the key approx. 4 sec programs certain
essential functions to the factory settings. These
include internal control with manual setpoint input,
standard control parameters etc.
